Ultra Slim Light Weight Full HD Led Resolution Display Narrow Pixel Pitch For TV Station

Name: Ultra Slim Light Weight Full HD Led Resolution Display Narrow Pixel Pitch For TV Station
Brand: Zhongyi
Price: 1 USD

China Ultra Slim Light Weight Full HD Led Resolution Display Narrow Pixel Pitch For TV Station wholesale

Brand Name : Zhongyi

Model Number : ZNI19

Certification : CE / RoHS / FCC / ETL / TUV

Place of Origin : Shenzhen, China

MOQ : 1 cabinet

Price : negotiatioin

Payment Terms : 30% T/T prepayment, 70% T/T balance before shipment

Supply Ability : 3000 squaremeter per month

Delivery Time : 28-32 working days after receiving your prepayment

Packaging Details : Plywood or Flight cases, 6 pcs in a flight cases(Recommend)

Pixel pitch : PH1.9mm

Brightness : 1000nits

Refresh : 3840HZ

Led Chip : Epistar

LED Lamp : SMD1515

IC : MBI5153

Power supplier : CE Power supplier

Connector : Neutrik or Seetronics

Cabinet materials : Die-casting

Cabinet weight : 7.5 kg per piece

Packing : Flight case

Warranty : 2 years or longer

IP : IP30

Contact Now

P1.9 Ultra Slim Light weight Precise UHD Led Display Front Maintenance

Quick details

400:300mm Die-casting cabinet Ratio 4:3

Reliable quality
6 layers PCB 2.0mm thickness

Nationstar led lamp SMD1515
MBI Ic from Taiwan

CE Power supplier 5V 60A

Classical design and natural tech., reliable quality and great performance.
Seamless connecting tech., screen flatness error <0.1mm.
Patented mask, eliminating the dark spots, improving consistency and viewing angle.

Detailed Specifications:
1. With pure golden wire connection in LED - Nationstar
2. Grand A row material for module frame and mask
3. 6 layers PCB and copper plating thickness > 18mil
4. Stainless steel screws when assembly
5. Disassembly and assembly are quick and easy
6. 3 to 5 years warranty
7. Energy-saving 60% : driving with low frequency current, heat-dissipated roller fans with automatic temperature-controlling device.

Now P1.9 ultra hd narrow pixel pitch led screens are widely used for Tv station ,conference and monitoring room...Also LED screen has its advantages like high brightness, good uniformity and grey,high contrast which beat DLP,LCD..

Ultra HD Narrow pixel pitch led screen are a trend in future, as led technology has been developped and revolution. Ultra HD p1.9 led screen is most hotseller in the market. We use best Epistar led chip and MBI high refresh IC, so that there is high grey 16 bits and no defective rate.

UHD-P1.9

Pixel Pitch(㎜)	1.923
Pixel Density(pixel/㎡)	270420
Pixel Component	1R1G1B
LED Configuration	SMD1010
Panel Dimension(W×H)㎜	200*150
Scan Mode	43126
Cabinet Dimension(W×H)㎜	400*300
Cabinet Material	Die-casting Aluminum
Cabinet Weight(㎏)	8.5
Brightness(cd/㎡)	≥800( Color Temperature6500K)
Color Temperature	3200K-9500K
Viewing Angle(V)	160°
Viewing Angle(H)	160°
Contrast Ratio	125.0006944
Max Power Consumption(w/㎡)	1000
Ave Power Consumption(w/㎡)	400
Operating Power Source	AC85~264V(47-63Hz)
Frame Frequency(Frame/S)	60
Refresh Rate(Hz)	≥2880
Gray Level	RGB65536Grade
Brightness Adjustment Level	256Grade
Brightness Adjustment Mode	Manual/Automatic/Programmable
Control Distance	UTP＜100m；Muti Mode Fiber＜500m；Single Mode Fiber＜10Km
Operating Temp	﹣20℃－﹢50℃
Operating Humidity	10%－90%RH
Protecting Rating	IP31
